| Imaging |
| Lens Mount |
Canon RF |
| Lens Communication |
Yes, with Autofocus Support |
| Sensor Resolution |
Actual: 9.6 Megapixel (4206 x 2280)
Effective: 8.85 Megapixel (4096 x 2160) |
| Sensor Type |
26.2 x 13.8 mm (Super35) CMOS |
| Pixel Pitch |
6.4 µm |
| Image Stabilization |
Digital, 5-Axis |
| Built-In ND Filter |
Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64), 8 Stop (1/256), 10 Stop (1/1024) ND Filters |
| Capture Type |
Stills & Video |
| Exposure Control |
| Shutter Type |
Electronic Rolling Shutter |
| Shutter Speed |
1/12 to 1/2000 Second |
| ISO Sensitivity |
Photo/Video
160 to 25,600 (Extended: 100 to 102,400) |
| Gain |
-6 to 54 dB (Native)
-2 to 54 dB (Expanded) |
| Shutter Angle |
11 to 360° |
| Advertised Dynamic Range |
16 Stops |
| White Balance |
2000 to 15,000K
Presets:AWB, Daylight, Set A, Set B, Tungsten |
| Internal Video Capture |
| Recording Modes |
XF-AVC 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
UHD 4K (3840 x 2160) at 24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
HD (1280 x 720) at 23.976p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 119.88p
UHD 4K (3840 x 2160) at 119.88p
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit
DCI 2K (2048 x 1080) at 179.82p
Full HD (1920 x 1080) at 179.82p
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [24 to 35 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [24 to 35 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [135 to 225 Mb/s]
UHD 4K (3840 x 2160) at 50p/59.94p [135 to 225 Mb/s]
2840 x 1080 at 23.976p/24.00p/25p/29.97p/50p/59.94p [50 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [50 Mb/s]
HD (1280 x 720) at 50p/59.94p [12 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [100 to 170 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [100 to 170 Mb/s]
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
HD (1280 x 720) at 50p/59.94p [9 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 119.88p
UHD 4K (3840 x 2160) at 119.88p
DCI 2K (2048 x 1080) at 179.82p
Full HD (1920 x 1080) at 179.82p
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [150 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [150 Mb/s]
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
HD (1280 x 720) at 50p/59.94p [8 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit
DCI 4K (4096 x 2160) at 119.88p
UHD 4K (3840 x 2160) at 119.88p
DCI 2K (2048 x 1080) at 179.82p
Full HD (1920 x 1080) at 179.82p |
| Sensor Crop Modes |
Super35 / APS-C
2K (2048 x 1080) |
| Variable Frame Rates |
DCI 4K: 12 to 119.88 fps
DCI 2K (Windowed): 12 to 179.82 fps |
| Gamma Curve |
Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Wide DR |
| Recording Limit |
Unlimited |
| Video System |
NTSC/PAL |
| Built-In Microphone Type |
Stereo
Mono |
| Audio Recording |
4-Channel 24-Bit 48 kHz LPCM Audio |
| External Video Capture |
| External Recording Modes |
4:2:2 10-Bit via HDMI
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p
HD (1280 x 720) at 23.976p/24.00p/25p/29.97p/50p/59.94p |
| IP Streaming |
Yes |
| Still Image Capture |
| Image Sizes |
JPEG
4096 x 2160
3840 x 2160
2048 x 1080
1920 x 1080 |
| Aspect Ratio |
16:9 |
| Image File Format |
JPEG |
| Bit Depth |
12-Bit |
| Interface |
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC |
| Video I/O |
1 xHDMI Output |
| Audio I/O |
2 xMini XLR Mic/Line (+48 V Phantom Power) Input
1 x 3.5 mm TRS Stereo Input
1 x3.5 mm TRS Stereo Headphone Output |
| Power I/O |
1 xBarrel (11.5 to 20 VDC) Input |
| Other I/O |
1 xUSB Type-C Control/Video Input/Output
1 xBNC (Timecode) Input/Output
1 x2.5 mm Sub-Mini (LANC) Control |
| Wireless |
None |
| Global Positioning (GPS, GLONASS, etc.) |
GPS
*Adapter Required |
| Monitor |
| Size |
3.5" |
| Resolution |
2,760,000 Dot |
| Display Type |
Articulating Touchscreen LCD |
| Focus |
| Focus Type |
Auto and Manual Focus |
| Focus Mode |
Automatic (A), Continuous-Servo AF (C), Manual Focus (M) |
| Environmental |
| Operating Temperature |
0 to 40°C (32 to 104°F) Recommended |
| Operating Humidity |
85% (Recommended) |
| Battery Type |
Canon BP-A Series |
| Tripod Mounting Thread |
2 x1/4"-20 Female (Bottom)
1 x3/8"-16 Female (Bottom)
1 x1/4"-20 Female (Side) |
| Accessory Mount |
1 x 1/4"-20 Female
2 xCold Shoe Mount |
| Dimensions (W x H x D) |
5.1 x 6.3 x 4.6" / 130.2 x 160 x 115.9 mm |
| Weight |
1.17 kg (2.58 lb) Body Only
1.34 kg (2.95 lb) With Battery |
