Metabones BMPCC4K > EF Speedbooster CINE XL 0.64x
- Specially designed for The BMPCC4K
- Gains 1 1/3 stops of light
- Reduces the MFT crop of 2,02x to 1,29x
- Locking EF-Mount
- For use with Full-Frame EF Lenses
€40,00 /Shoot Day
1 Day
2 Days
3 Days
4 Days
5 Days
1 Week
€40,00
€76,00
€108,00
€136,00
€160,00
€196,00
+ 10% discount for online bookings · Prices excl. VAT and 7% insurance
- Often rentedOften rentedtootooOften rented
- Description &Description &In the CaseIn the CaseDescription
- TechnicalTechnicalSpecificationsSpecificationsSpecifications
- Manuals &Manuals &DownloadsDownloadsManuals
Often rented too
-
Fluid Heads & Tripods
Sachtler Cine 7+7 HD 100mm Bowl with Flowtech 100 System
- 100mm Ball Head Supports up to 22 kg
- Lightweight dual-stage flowtech tripod
- Total system weight: 7.5 kg
- Mid-level spreader and rubber feet
- SpeedLevel Clamp for quick leveling
- Payload boost button
- 16 Steps of counterbalance
- Speedbalance technology
- Touch & go plate
- Carrying handle
-
-
-
Metabones BMPCC4K > EF Speedbooster CINE XL 0.64x Specs
| Optical | |
|---|---|
| Canon EF mount lens to Blackmagic Design cameras with M43 mount, specific for BMPCC4K. | |
| Increase maximum aperture by 1/3 stop (with a maximum output aperture of f/0.80). | |
| Increase MTF. | |
| Makes lens 0.64x wider. | |
| Patented 7-element/4-group optical design by Caldwell Photographic in the USA. | |
| Electronic | |
| Lens iris/aperture is set by the controls on the camera body. | |
| Smooth iris support with the latest Canon (2009+), Tamron (SP series 2013+) and Sigma (2016+) lens models. | |
| Image stabilization (IS) lens support. | |
| Push autofocus if supported by camera. | |
| Powered by camera body. With most lenses, no external power source required. | |
| Mechanical | |
| Patented positive-lock EF lens mount. | |
| Detachable tripod foot compatible with Arca-type ball heads such as Arca Swiss, Markins and Photo Clam, or attach to a quick release plate by a 1/4"-20 screw. | |
| The tripod foot is tailor-made to match the exact height of the BMPCC4K camera body. | |
| Flocking to reduce internal reflection. | |
| Rubber gasket protects the M43 mount connection from dust and moisture. | |
| Aluminum alloy and brass construction with chromium plating. | |
| Satin surface finish. | |
| Compatible Cameras | |
| Blackmagic Pocket Cinema Camera 4K Blackmagic Pocket Cinema Camera HD (Original) Blackmagic Micro Cinema Camera Blackmagic Micro Studio Camera 4K Blackmagic Studio Camera 4K Blackmagic Studio Camera |
|
| Compatible Lenses | |
| Canon EF100-400mm f/4.5-5.6L IS II USM Canon EF100-400mm f/4.5-5.6L IS USM (I) Canon EF100mm f/2.8L IS USM Macro* Canon EF135mm f/2L USM Canon EF16-35mm f/2.8L II USM* Canon EF17-35mm f/2.8L USM Canon EF17-40mm f/4L USM Canon EF200mm f/2.8L II USM Canon EF24-105mm f/4L IS USM (I) Canon EF24-70mm f/2.8L II USM* Canon EF28-135mm f/3.5-5.6 IS USM Canon EF28-70mm f/3.5-4.5 II Canon EF28-80mm f/3.5-5.6 III USM Canon EF300mm f/2.8L IS II USM* Canon EF300mm f/4L IS USM Canon EF400mm f/5.6L USM Canon EF40mm f/2.8 STM* Canon EF50mm f/1.2L USM Canon EF50mm f/1.4 USM Canon EF50mm f/1.8 II Canon EF50mm f/1.8 STM* Canon EF70-200mm f/2.8L IS II USM* Canon EF70-200mm f/4L IS II USM* Canon EF70-200mm f/4L USM Canon EF70-300mm f/4-5.6L IS USM Canon EF8-15mm f/4L USM Fisheye* Canon EF85mm f/1.2L II USM Sigma 135mm f/1.8 DG HSM Art 017* Sigma 24-105mm f/4 DG HSM Art 013 SIgma 24-35mm f/2 DG HSM Art 015 Sigma 35mm f/1.4 DG HSM Art 012* Sigma 50-500mm f/4.5-6.3 DG OS HSM Sigma 50mm f/1.4 DG HSM (not Art) Tamron 10-24mm f/3.5-4.5 VC HLD B023 Tamron 18-250mm f/3.5-6.3 A18 Tamron 18-270mm f/3.5-6.3 B003 Tamron 24-70mm f/2.8 VC USD A007 (G1) Tamron 28-300mm f/3.5-6.3 A06 Tamron 35-150mm f/2.8-4 VC OSD A043 Tamron 70-200mm F/2.8 Di VC USD A009 Zeiss 18mm f/3.5 ZE Canon EF-Extender (Teleconverter) |
|
| * = Smooth iris support | |
| Incompatible | Tamron 70-300mm F/4-5.6 VC USD A005 |
| Limitations | |
| No Lens OIS/VC Support | Tamron SP 15-30/2.8 VC USD A012 Tamron 45mm F/1.8 VC USD F013 Tamron 150-600mm F/5-6.3 VC USD A011 |
| No AF Support | Tamron SP 17-50mm F/2.8 VC B005 Tamron 28-300mm F/3.5-6.3 VC A20 Tokina Opera 50mm F/1.4 Sigma 18-125mm F/3.5-5.6 DC OS HSM Canon EF100-400mm F/4.5-5.6L IS II USM |
| No Iris Support without External Power Supply | Canon EF24-70mm F/2.8L USM (I) Canon EF100mm F/2.8 USM Macro (non-L) Tamron 18-270mm F/3.5-6.3 VC PZD B008 |
| Unsupported | |
| Standard M43 cameras — when this Speed Booster is used with other MFT cameras, it may cause damage to the camera. | |
| APS-C (DX) lenses — Speed Booster XL 0.64x can be used with full-frame lenses only; APS-C lenses are unable to cover full-sensor-width readout. | |
| EF-S lenses — require modification to fit or may remain incompatible even after modification. | |
| Lens corrections such as peripheral shading, CA and distortion. | |
| Focus confirmation chips (e.g. Dandelion). | |
| M42 screw mount adapters (see note 5). | |
| Stacking non-Metabones/non-Conurus mount adapters on top (see note 5 and the modification list below). | |
| Notes | |
| 1. This Speed Booster is designed to cover the BMPCC4K image circle — not a full-size 36 x 24 mm sensor. | |
| 2. For use with fast lenses (faster than f/1.4), the pre-boost apertures will be displayed in the camera: slow lenses report boosted apertures, fast lenses report pre-boost apertures. Example: EF 85/1.2L → display f/1.2, physical f/0.77 · EF 35/2 → display f/1.3, physical f/1.3. | |
| 3. External 5V power via the micro USB port may be required (not included). | |
| 4. A third-party zoom lens may need to be registered with the Speed Booster/Smart Adapter first in order to detect its maximum aperture. | |
| 5. Some improperly-made M42 screw mount adapters may short the electronic contacts and cause damage to the Speed Booster and/or camera body. | |
| 6. Many manual focus lenses (e.g. OM 28/2.8, OM 50/1.8, Leica R 15/3.5) have rear protrusions which can damage the optics and/or housing of the Speed Booster — check before use and modify if necessary; such damage is not covered by warranty. | |
| Manual Focus Lenses that Require Modification | |
| Leica R | Super-Elmar-R 15mm Elmarit R 28/2.8 Elmarit R 35/2.8 Summicron R 50/2 |
| Nikon F | 20/2.8 AI-S |
| Olympus OM | OM 18/3.5 OM 21/2 OM 21/3.5 OM 28/2.8 OM 50/1.8 |
| Pentax K | Every Pentax K-mount lens has a protruding fin and an aperture lever — it does NOT fit. |
Description &In the Case
Description
The BMPCC4K Speed Booster ULTRA 0.71x and XL 0.64x are similar to the standard M43 Speed Booster adapters (MB_SPEF-m43-BT5 or MB_SPEF-m43-BT6), but the optics have been redesigned to optimize them for the 2.4 mm filter stack thickness. So they are compatible with Blackmagic cameras instead of standard Micro Four Thirds.
In addition to the optimized optical design, the CINE version is equipped with an extremely robust, positive locking mechanism in cine format, which ensures that there is no play when focusing. This is particularly important when using EF lenses from the cine range, as they allow very smooth focusing.
The BMPCC4K Speed Booster XL 0.64x reduces the crop factor of the BMPCC 4K camera from 2.02x to 1.29x and produces the largest aperture currently available with a maximum value of f/0.8. Metabone’s XL adapters are particularly suitable for full-frame lenses, while the ULTRA series are available for DX/APS-C lenses.
Attention: Metabones Canon EF to BMPCC4K Speed Booster Adapters have been developed exclusively for the Blackmagic Design Pocket Cinema Camera 4K (BMPCC4K). They cannot be connected to other M4/3 cameras such as JVC, Olympus or Panasonic cameras.
In the Case
- Metabones BMPCC4K > EF Speedbooster CINE XL 0.64x
- 2x hex keys
- Screw-on base
- 2x plugs in bag
- 2x caps
- Original box
