ARRI SkyPanel S60-C LED Softlight

  • Fully tuneable, high output LED light
  • True soft light beam quality
  • Outstanding color rendition
  • Multi-way controlable
  • Built-in lighting effects


The ARRI SkyPanel S60-C LED Softlight is a mid-range model, featuring a light aperture of 645 x 300 mm and accommodating the vast majority of applications.Unlike other tuneable fixtures, SkyPanel makes no sacrifice when it comes to light output. SkyPanel puts out a tremendous amount of light, in a soft and uniform beam field. Brighter than a 2 kW tungsten soft light or a 6 kW tungsten space light, the SkyPanel S60 has more than enough light for most applications. At the same time, the lamphead is able to perform beautifully at lower light levels. This range of illumination and color gives users an unprecedented amount of control.

Outstanding Color Rendition

ARRI has always been at the forefront of LED white light color quality and SkyPanel lives up to this standard. Natural rendition of skin tones, accurate color reproduction and precise color temperature settings are all areas where SkyPanel excels. Whether you measure the color rendition using CRI (Color Rendering Index), CQS (Color Quality Scale) or TLCI (Television Lighting Consistency Index), SkyPanel performs beautifully.

Impressive Lighting Effects

The state-of-the-art light engines and electronics built into every SkyPanel have paved the way for a powerful new feature: lighting effects. With SkyPanel Lighting Effects users can now choose and manipulate several effects without the need for a lighting console or hours of programming. Each effect has several parameters that allow for customization of the effect to fit your needs.

The lighting effects include: candle, clouds passing, club lights, color chase, cop car, fire, fireworks, light strobe, lightning, paparazzi, pulsing, television, processing, welding, explosion and more. SkyPanel Lighting Effects changes the game for on-set lighting effect generation.

In the Case
  • ARRI SkyPanel S60-C
  • 3m XLR3 power cable
  • Standard diffusor
  • Heavy diffusor
  • Light diffusor
  • Intensifier
  • Skypanel diffusor bag
  • DOP Choice snapbag
  • DOP Choice snapgrid
  • 4x diffusion for snapbag (1, 1/2, 1/4, Magic)
  • Power supply
  • Power supply holding bracket
  • AC cable
  • Skypanel remote with bag
  • USB cable for skypanel remote
  • Lanyard
  • Remote accessory bag
  • Acessory bag
  • V-mount battery plate
  • 2x XLR4 battery plate power cable
  • 10mm hex key and 4mm t-hex key
  • 2x manual
  • Porta Brace LPB-S bag
  • Shoulder strap
  • Hand strap
Light Fixture
Beam Angle 115°
Color Temperature 2800 to 10,000K ± 100K (with 200K Shift over Lifetime)
Color Accuracy Standard CRI 95
Cooling System None
Dimming Yes, 0 to 100% (Continuous)
Display None
Expected Lamp Life 50,000 Hours
Rectangular Panel Size 64.5 x 30 cm (25.4 x 11.8″)
Fixture Dimensions 688.0 x 433.0 x 133.0 mm (27.0 x 17.0 x 5.2″)
Fixture Weight 12 kg (26.5 lb)
Power Input Connector 3-Pin XLR
DMX Connector 5-Pin XLR, EtherCON
Service Connector USB Type-A
Yoke Mount TVMP/ Hex Bolt
Fixture Mount 1-1/8″ Stud
Accessory Mount None
Yoke Material Steel
Remote Operation
Remote Control Type DMX
AC Input Power 90 to 250 VAC, 50 / 60 Hz
DC Input Power 48 VDC
Power Source AC Adapter, External Battery
Power Supply
Power Supply Power Connector powerCON Input
Power Supply Weight 5.0 kg (11 lb)
Cable Type powerCON to NEMA 5-15
IP Rating IP20
Operating Temperature -20 to 45°C (-4 to 113°F)
