Teradek Bolt 1000 XT Wireless System


  • Up to 300m range with zero delay
  • Dual input (SDI + HDMI) and SDI loop out on TX
  • HDMI and Dual 3G-SDI outputs on RX
  • Cross conversion
  • Compatible with Bolt 1000, Sidekick II, Bolt 1000 LT, and 703 Bolt
  • 3D LUTs, 5GHz spectrum analyzer, manual channel selection
  • Robust mounting points (3/8” and ¼”-20)

200,00

The Bolt 1000 XT satisfies the needs of the most discerning professionals, from powerful software tools and rock-solid performance to smart power options and backward compatibility.A key feature of the Bolt 1000 XT is its backward compatibility with any Bolt of the same range, Sidekick II / LT / XT, and 703 Bolt, giving users more flexibility building onto their existing systems or linking with others already on set. Unlike alternative wireless video systems, Bolt 1000 XT includes a unique AES 128 encryption algorithm to protect your video footage, ensuring that only authorized receivers can connect to your transmitter.

The transmitter includes an HDMI, 3G-SDI and looping 3G-SDI output. The receiver features an HDMI output as well as dual 3G-SDI outputs. While wireless performance is critical on set, so are practical mounting options that ensure optimal performance and a quick set-up.

The Bolt 1000 XT, like the previous generation, is multicast capable up to 4 receivers and includes built-in cross conversion and Teradek’s proprietary software utilities, including a manual frequency-selection tool, 3D LUT engine, and a 5GHz spectrum analyzer to keep an eye on interference in your area.

In the Case
  • TX unit
  • RX unit
  • 7x antenna
  • 2x 50cm HDMI cable
  • 2x 75cm HDMI cable
  • 2x coiled BNC cable
  • 2x straight > 90° BNC cable
  • 4x D-Tap > Lemo power cable
  • USB cable
  • Cold shoe mounting screw (3 parts)
  • Rapid adapter (3 parts)
  • AC adapter
  • Manual
  • Original hard case

Have a look at our other Bolt systems

Bolt 1000 XT 3G-SDI/HDMI Wireless Transmitter

Construction Milled aluminum (chassis) and regulation-compliant PCB
Video Inputs SDI: 1 x BNC (75 Ohm), 3G/HD/SD
HDMI: 1 x HDMI type A receptacle
Video Outputs SDI: 1 x BNC (75 Ohm), 3G/HD/SD, loop through
Color Sampling SDI: YCbCr 4:2:2, 10-bit (8-bit when format conversion is enabled)
HDMI: RGB 4:4:4, 8-bit
Latency <0.001 seconds (Tx to Rx without format conversion)
Channels 40 MHz: 11
Supported Resolutions 1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
480i: 59.94
576i: 50
Video Processing Compression
Visually losslessColor Correction
CDL/1024 1D LUT (supports 10-bit color)
33x33x33 3D LUT (supports 10-bit color)
Audio Compression 48 kHz, 24-bit PCM
Audio Input Embedded
Interfaces Switches: On/Off and Reset
Desktop App: Feature-rich Bolt Manager application for Mac OS X and Windows
USB Interface Functionality: Upgrade via mini-USB
Wireless Non-DFS Frequencies

  • UA: 5.19 to 5.23 GHz, 5.755 to 5.795 GHz
  • EU & JP: 5.19 to 5.23 GHz

DFS Frequencies

  • US: 5.27 to 5.55 GHz and 5.67 GHz
  • EU & JP: 5.27 to 5.67 GHz
RF Power 17 dBm EIRP
Encryption AES-128
Range Up to 500′ / 152.4 m line of sight
Unicast Multicast Unicast / Multicast
Noise Rejection Can coexist with WiFi and 5 GHz cordless phones
Power Input 2-pin connector
7 to 17 VDC
Power Consumption Nominal 7.3 W (measured at 1080p60)
Operating Temperature 0 to 40°C (32 to 104°F)
Mountable 1 x 1/4″-20 threaded mounting hole
2 x M3 threaded mounting holes
Dimensions 2.41 x 6.6 x 11.35 cm (0.95 x 2.6 x 4.47″)
Weight 226 g (8 oz)

Bolt 1000 XT 3G-SDI/HDMI Wireless Receiver

Construction Milled aluminum (chassis) and regulation-compliant PCB
Video Outputs SDI: 1 x BNC (75 Ohm), 3G/HD/SD
HDMI: 1 x HDMI type A receptacle
USB: 1 x USB-type 3.0 Micro B receptacle
SDI Ancillary Data Support Supports metadata, timecode, and start/stop flags from select camera manufacturers.
Color Sampling SDI: YCbCr 4:2:2, 10-bit (8-bit when format conversion is enabled)
HDMI: RGB 4:4:4, 8-bit
Latency <0.001 seconds (Tx to Rx without format conversion)
Supported Resolutions 1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576P: 50 (via HDMI only)
480p: 59.94 (via HDMI only)
576i: 50
480i: 59.94
Video Processing Compression
Visually losslessColor Correction
CDL/1024 1D LUT (supports 10-bit color)
33x33x33 3D LUT (supports 10-bit color)
Audio Compression 48 kHz, 24-bit PCM
Audio Input Embedded
Interfaces Switches: On/Off and Reset
Desktop App: Feature-rich Bolt Manager application for Mac OS X and Windows
USB Interface Functionality: Upgrade via mini-USB
Wireless Non-DFS Frequencies

  • UA: 5.19 to 5.23 GHz, 5.755 to 5.795 GHz
  • EU & JP: 5.19 to 5.23 GHz

DFS Frequencies

  • US: 5.27 to 5.55 GHz and 5.67 GHz
  • EU & JP: 5.27 to 5.67 GHz
RF Power 15 dBm EIRP
Encryption AES-128
Range Up to 500′ / 152.4 m line of sight
Unicast Multicast Unicast / Multicast
Noise Rejection Can coexist with WiFi and 5 GHz cordless phones
Power Input 2-pin connector
7 to 28 VDC
Power Consumption Nominal 9 W (measured at 1080p60)
Operating Temperature 0 to 40°C (32 to 104°F)
Mountable 1 x 1/4″-20 threaded mounting hole
2 x M3 threaded mounting holes
Dimensions 8.89 x 13.72 x 2.41 cm (3.5 x 5.4 x 0.95″)
Weight 377 g (13.3 oz)
