Sony DSC-RX0 Action-Cam

Sensor

SENSOR TYPE

1.0-type (13.2mm x 8.8mm) Exmor RS™ CMOS sensor, aspect ratio 3:2

NUMBER OF PIXELS (EFFECTIVE)

15.3MP

NUMBER OF PIXELS (TOTAL)

Approx. 21.0 Megapixels

Lens

LENS TYPE

ZEISS Tessar T* Lens, 6 elements in 6 groups (6 aspheric elements)

F-NUMBER (MAXIMUM APERTURE)

F4.0 (Fixed)

FOCAL LENGTH (F=)

f=7.7mm;Still Image3:2 f=24mm;Still Image4:3 f=26mm;Still Image16:9 f=25.2mm;Still Image1:1 f=30.7mm

FOCUS RANGE (FROM THE FRONT OF THE LENS)

Approx. 50cm (1.7 ft.) to Infinity

3.8cm(1.5type)(4:3) / 230,400 dots / Clear Photo / TFT LCD

BRIGHTNESS CONTROL

Manual(5 steps) / Sunny Weather

MF ASSIST MAGNIFICATION

8.6x

IMAGE PROCESSING ENGINE

Yes (BIONZ X™)

FOCUS MODE

Single-shot AF;Preset Focus;Manual Focus

FOCUS AREA

Wide (25 points(contrast-detection AF));Center;Flexible Spot (S/M/L);Expanded Flexible Spot

LIGHT METERING MODE

Multi Pattern;Center Weighted;Spot

EXPOSURE COMPENSATION

+/- 3.0EV, 1/3EV step

ISO SENSITIVITY (STILL IMAGE)(RECOMMENDED EXPOSURE INDEX)

Auto(ISO125-12800, selectable with upper / lower limit),125/160/200/250/320/400/500/640/800/1000/1250/1600/2000/2500/3200/4000/5000/6400/8000/10000/12800 (Extendable to ISO80/100),Multi-Frame NR:Auto(ISO125-12800), 200/400/800/1600/3200/6400/12800/25600

ISO SENSITIVITY (MOVIE)

Auto:(ISO125Level-ISO12800Level, selectable with upper / lower limit), 125/160/200/250/320/400/500/640/800/1000/1250/1600/2000/2500/3200/4000/5000/6400/8000/10000/12800

MINIMUM ILLUMINATION (MOVIE)

Auto:6lux(Shutter Speed 1/30″)

WHITE BALANCE MODES

Auto;Daylight;Shade;Cloudy;Incandescent;Fluor.: Warm White;Fluor.: Cool White;Fluor.: Day White;Fluor.: Daylight;Underwater Auto;C.Temp./Filter;Custom

WB MICRO ADJUSTMENT

YesG7 to M7,57-stepA7 to B7,29-step

ELECTRONIC SHUTTER

iAuto(1/4″ – 1/32000) / Program Auto(1/4″ – 1/32000) / Manual(1/4″ – 1/32000)

APERTURE

F4.0

IMAGE CONTROL

Contrast;Saturation;Sharpness;Creative Style;Color Space(sRGB / Adobe RGB);Quality(RAW / RAW&JPEG / Extra fine / Fine / Standard)

NOISE REDUCTION

high ISO NR:Normal/Low/Off;Multi Frame NR: Auto, ISO200-25600

DYNAMIC RANGE FUNCTIONS

Off, Dynamic Range Optimizer (Auto/Level 1-5), Auto High Dynamic Range (Auto Exposure Difference, Exposure difference Level (1.0-6.0EV, 1.0EV step))

SHOOTING MODE

Program Auto;Manual Exposure;MR(Memory Recall) [body 3 sets / memory card 4 sets];Movie Mode(Intelligent Auto);Movie Mode(Program Auto);Movie Mode(Manual Exposure);HFR Mode(Program Auto, Manual Exposure);Intelligent Auto;Superior Auto

CONTINUOUS SHOOTING SPEED (MAXIMUM) (WITH MAX. RECORDING PIXELS)

Speed Priority Continuous Shooting: approx. 16 fps, Continuous Shooting: approx. 5.5 fps

SELF-TIMER

10sec. / 5sec. / 2sec. / 3 or 5 consecutive shots with 10sec. 5sec. or 2sec. delay selectable / Bracketing shots with 10sec. 5sec. or 2sec. delay selectable

DRIVE MODES

Single;Continuous shooting;Speed priority continuous shooting;Self-timer;Self-timer(cont.);Cont.-bracketing, Single-bracketing, White balance bracketing, DRO bracketing

PICTURE EFFECT

Still Image:Pop Color;Posterization;Retro Photo;Soft High-key;Partial Color;High Contrast Mono.;Soft Focus;HDR Painting;Richtone Monochrome;Miniature;Watercolor;Illustration;Movie:Pop Color;Posterization;Retro Photo;Soft High-key;Partial Color;High Contrast Mono.

CREATIVE STYLE

Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn Leaves, Black & White, Sepia, Style Box

PICTURE PROFILE

Off/PP1-PP7(Black Level, Gamma(Movie, Still, Cine1-2, ITU709, ITU709 [800%], S-Log2), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset)

FOCUS TYPE

Contrast-detection AF

NUMBER OF RECOGNISED SCENES

Still Image:Superior Auto: 10 / iAuto: 10;10

Recording

COMPATIBLE RECORDING MEDIA

Memory Stick Micro, Memory Stick Micro (Mark2), microSD Memory Card, microSDHC Memory Card, microSDXC Memory Card

RECORDING FORMAT

Still Image:JPEG(DCF Ver.2.0,Exif Ver.2.31,MPF Baseline compliant), RAW (Sony ARW 2.3 format);XAVC S;AVCHD format Ver.2.0 compatible;MP4

RECORDING FORMAT (MOVIE AUDIO)

XAVC S:LPCM 2ch;AVCHD:Dolby Digital(AC-3) 2ch(Dolby Digital Stereo Creator);MP4:MPEG-4 AAC-LC 2ch

COLOUR SPACE (STILL)

sRGB, Adobe RGB

DCF/DPOF

DCF/DPOF/EXIF/MPF

STILL IMAGE NUMBER OF RECORDED PIXELS (IMAGE SIZE)

Still Image:3:2mode:15M(4,800×3,200) / 7.7M(3,408×2,272) / 3.8M(2,400×1,600)、4:3mode:14M(4,272×3,200) / 6.9M(3,024×2,272) / 3.4M(2,128×1,600) / VGA,16:9mode:13M(4,800×2,704) / 6.5M(3,408×1,920) / 3.2M(2,400×1,352),1:1mode:10M(3,200×3,200) / 5.2M(2,272×2,272) / 2.6M(1,600×1,600)

HFR

RecordingNTSC/PAL Selector: [PAL] mode XAVC S HD:50p 50M(1,920×1,080/250fps), 50p 50M(1,920×1,080/500fps), 50p 50M(1,920×1,080/1000fps) / 25p 50M(1,920×1,080/250fps), 25p 50M(1,920×1,080/500fps), 25p 50M(1,920×1,080/1000fps), NTSC/PAL Selector: [NTSC] mode XAVC S HD:60p 50M(1,920×1,080/240fps)、60p 50M(1,920×1,080/480fps)、60p 50M(1,920×1,080/960fps) / 30p 50M(1,920×1,080/240fps)、30p 50M(1,920×1,080/480fps)、30p 50M(1,920×1,080/960fps) / 24p 50M(1,920×1,080/240fps)、24p 50M(1,920×1,080/480fps)、24p 50M(1,920×1,080/960fps)Sensor Readout Number of effective pixelsQuality Priority:240fps/250fps(1,676×942),480fps/500fps(1,676×566),960fps/1000fps(1,136×384)/Shoot Time Priority:240fps/250fps(1,676×566),480fps/500fps(1,136×384),960fps/1000fps(800×270)

STILL IMAGE NUMBER OF RECORDED PIXELS (IMAGE SIZE) DURING MOVIE

–

Interface

INPUT AND OUTPUT TERMINALS

Multi/Micro USB Terminal,  Hi-Speed USB (USB2.0), Micro HDMI, Microphone jack(3.5mm Stereo mini jack)

NFC

–

WI-FI

Yes(IEEE802.11b/g/n(2.4GHz band))

INTERFACES

–

BLUETOOTH

Yes (Bluetooth Standard Ver. 4.1 (2.4GHz band))

Power

POWER SOURCE

DC3.7V(supplied battery) / DC5.0V(supplied AC Adaptor)

BATTERY SYSTEM

Rechargeable battery pack NP-BJ1

POWER CONSUMPTION (CAMERA MODE)

Approx. 1.3W

USB CHARGE/USB POWER SUPPLY

Yes (Shooting, Playback,)

Others

SHOOTING FUNCTIONS

Eye AF;Face Detection;Face Registration;Grid Line;WB Bracket;DRO Bracketing;MF Assist;Peaking;Zebra;Marker Display;Audio Level Display;TC/UB;Photographer Name & Copyright;ISO Auto Minimum Shutter Speed;PC Remote Controll;Gamma Disp. Assist;Flip

PLAYBACK FUNCTIONS

BRAVIA Sync(Control for HDMI);9/25-frame index view;Slide Show;Forward/Rewind (Movie);Delete;Protect

TRILUMINOS COLOR

Yes

4K IMAGE OUTPUT

Yes

OPERATING TEMPRATURE

0 degrees C. – +40 degrees C. / 32 degrees F. – 104 degrees F.

WATERPROOF

Yes (IPX8 equivalent)

SHOCKPROOF

Yes (2.0m/6.5ft MIL-STD810G C1 Method516.7-Shock)

CRUSHPROOF

Yes(200kgf/2000N/440lbf)

DIMENSIONS (W X H X D)

59.0×40.5×29.8 mm (2 3/8 in. × 1 5/8 in. × 1 3/16 in.)
