| Video |
| Video Inputs |
1 x HDMI Type-A receptacle |
| Bonding |
ShareLink |
| Supported Resolutions |
1080p 23.98/24/25/29.97/30
1080i 50/59.94/60
720p 50/59.94/60
576i/p
480i/p |
| Video Processing |
| Video Compression |
H.264, Baseline, Main Profiles |
| Supported Video Bitrate |
250 Kbps to 5 Mbps |
| Supported Video Bitrate Details |
Full HD: 5.2 Mbit/s
HD+:3.0 Mbits/s
HD:2.2 Mbit/s
High: 1.4 Mbit/s
Medium: 796 Kbit/s
Low: 446 Kbit/s
Mobile: 273 Kbit/s |
| Supported Output Resolutions 16/9 |
16:9 Widescreen:
Full HD: 1920 x 1080
HD+: 1280 x 720
HD: 1280 x 720
High: 960 x 540
Medium: 736 x 414
Low: 480 x 270
Mobile: 360 x 200
4:3 Outputs:
Full HD: 1440 x 1080
HD: 960 x 720
High: 720 x 540
Medium: 560 x 414
Low: 368 x 270
Mobile: 272 x 200 |
| Video Format Conversion Support |
Built-in Video Scaler and DeInterlacer |
| Protocol Support |
| Network Protocols |
TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP |
| Supported Video Transport Protocols |
RTMP |
| Software Or Platform Integration |
Ustream, YouTube Live, Facebook & new Livestream |
| Audio Processing |
| Audio Compression |
Audio compression: AAC-LC |
| Supported Audio Bitrate Details |
HD: 256kbps
High: 192kbps
Medium: 128kbps
Low: 96kbps
Mobile: 48kbps |
| Inputs |
| Audio Input |
Embedded audio input, 2 Channel
Analog line or mic-in, 2 Channel |
| Outputs |
| Audio Output |
Headphone output, adjustable volume |
| Dimensions |
119.38 x 76.2 x 30.48mm (4.7" W x 3" D x 1.2" H) |
| Weight |
198g (6.7oz) |
| Construction |
ABS Plastic |
| Mountability |
Can be mounted horizontally with
1/4" 20 mounting holes |
| Interfaces |
| HTTP |
WebUI for Configuration and Control |
| Configuration Interfaces |
OLED display with joystick navigation buttons
Feature-rich WebUI for configuration and control |
| Switches |
On/Off and reset switch |
| Recording Storage |
SD/SDHC (class 6 and above) formatted FAT32
USB formatted FAT32 |
| Mobile App |
VidiU App for iOS and Android devices |
| Usb Interface Functionality |
1x Powered USB 2.0 host port |
| Network |
| Ethernet |
10/100BASE-T |
| Wireless |
WiFi: Dual Band MIMO 802.11 a/b/g/n |
| USB |
USB 3G/4G modem support |
| Rf Channel Selection |
Auto with 3 modes: (2.4 or 5 Ghz), Auto (2.4 GHz only), Auto (5 Ghz only)
Configurable to specific channels |
| Power |
| Power Input |
6-18V DC Barrel Adapter |
| Battery |
Internal Rechargeable Lithium-ion Battery |
| Nominal Power Consumption |
4.5W (while charging: up to 10W) |
