BNC Cable Set

  • Assortiment of Belden 1505F 75 Ohms Coaxial Cables
  • Use for SDI and HDTV Environments
  • Set includes BNC couplers


The BNC Cable Set contains a wide variety of flexible HD/3GSDI Belden 1505F coaxial cable cables with high quality double braided shield in combination with Neutrik BNC connectors.

Ideal for mobile live production applications, the cables are highly durable and hardly tends to loop – designed for SDI and HDTV environments.

In the Case
  • 15x 1,5m BNC cable
  • 5x 3m BNC cable
  • 5x 5m BNC cable
  • 5x 10m BNC cable
  • 10x BNC coupler
  • EQC bag
  • Hard case
Categories: ,
Inner conductor: 7/0.287mm (7/29AWG) (0.45mm sq.) plain copper
Dielectric: Gas injected foam high density polyethylene, 3.68mm OD
Screen 1: Tinned copper braid, optical coverage 94%
Screen 2: Tinned copper braid, optical coverage 94%
Construction: Coaxial cable
Jacket: PVC, black red, yellow, violet (green, orange and white to special order, subject to minimum order quantities)
Overall diameter: 6.15mm
Impedance: 75 +/- 3% ohms
Capacitance: 55.7pF/m nominal
Velocity of propagation: 78%
Return loss: 15dB nom. 5-3000MHz
Attenuation: MHz 1 10 135 180 270 360 540 750
dB/100m 0.65 2.95 11.48 13.45 16.73 19.68 24.27 29.20
