SmallHD 703 Bolt Wireless Director’s Monitor 7″

  • 7″ 1920 x 1080 display
  • Integrated Teradek sidekick wireless RX
  • SDI local inputs
  • Bright 3000 cd/m² LCD panel
  • Power via 2-Pin LEMO
  • HD Scopes and exposure tools


The SmallHD 703 Bolt 7″ Wireless Director’s Monitor is an all-in-one director’s monitor solution. Borrowing the wireless technology from Teradek, the 703 Bolt can receive uncompressed HD wireless signals from Bolt 500, 1000, or 3000 transmitters up to 300′ away with no perceptible latency.With this feature, anyone can walk around the set while monitoring a camera feed, perfect for directors and camera assistants. Furthermore, despite the presence of a wireless receiver, the 703 Bolt maintains a slim profile similar to on-camera monitors.

At your fingertips

PageBuilder OS is an intuitive graphical user interface (GUI) that puts all the advanced functionality of the 703 Bolt at your fingertips.

Rather than have confusing menus, this GUI allows you to selectively apply monitoring tools such as waveform, vectorscope, multiview, LUTs, and focusing aids on different “pages”. These pages can be easily flipped through using the joystick. The buttons on the front panel can also toggle monitoring tools on and off for each page.

In the Case
  • SmallHD 703 Bolt
  • 3x antenna
  • Shoulder strap
  • Hard case

Book your suitable transmitter

Panel Type IPS-Type LCD
Display Size 7.0″ / 17.8 cm
Screen Resolution 1920 x 1080
Aspect Ratio 16:9
Viewing Angle Horizontal: 160°
Maximum Brightness 3000 cd/m2
Contrast Ratio 1150:1
Bit Depth / Color Support 8-Bit (16.7 Million Colors)
Pixels Per Inch (ppi) 323 ppi
Color Gamut 70% NTSC
Image Controls Blue Only, False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Waveform
Video 1 x 3G-SDI (BNC) Input/Output
1 x HDMI Type A Output
1 x 3G-SDI (BNC) Input
Embedded Audio SDI
Audio 1 x 3.5 mm Headphone Output
Built-In Speaker None
Power 1 x 2-Pin LEMO Input
Other I/O 1 x Wireless Receiver
Card Slot 1 x SD
Format Support
Video Format SDI (10-Bit 4:2:2 YCC)
1080p: 23.98/24/25/29.97/30/50/59.94/60
1080PsF: 23.98/24/25/29.97/30
1080i: 50/59.94/60
720p: 23.98/24/25/29.97/30/50/59.94/60
Wireless (10-Bit 4:2:2)
1080p: 23.98/24/25/29.97/30/50/59.94/60
1080PsF: 23.98/24/25/29.97/30
1080i: 50/59.94/60
720p: 50/59.94/60
DC Input Power 6 to 34 VDC
Battery Type None
Power Consumption 16 W
Mounting 4 x 1/4″-20 Female
Certifications CE, FCC, RoHS, as per Manufacturer
Operating Temperature -17.8 to 37.8°C (0 to 100°F)
Storage Temperature -20 to 48.9°C (-4 to 120°F)
Weight 1.25 kg (2.8 lb)
