| Connections |
| SDI Video Inputs |
4 x 10-bit SD-SDI and HD-SDI. |
| SDI Video Outputs |
1 x HD-SDI. |
| SDI Rates |
270Mb, 1.5G, 3G. |
| SDI Video Multi View Outputs |
1 x 10-bit HD-SDI. |
| HDMI Video Multi View Outputs |
1 x HDMI type A connector.
Output supports EDID of the monitor. |
| SDI Reclocking |
On all SDI outputs, auto switching between standard definition or high definition. |
| Reference Input |
None |
| Multi Rate Support |
Auto detection of SD or HD. |
| Updates |
USB 2.0 high speed (480Mb/s) interface. |
| Configuration |
USB 2.0 |
| Standards |
| SD Video Standards |
525i59.94 NTSC, 625i50 PAL |
| HD Video Standards |
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080i50, 1080i59.94, 1080i60 |
| 2K Video Standards |
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p |
| SDI Compliance |
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 425M-B, ITU‑R BT.656 and ITU‑R BT.601. |
| Audio Meters |
Each view, VU standard. |
| Source Routing |
None |
| SDI Video Sampling |
4:2:2 and 4:4:4. |
| SDI Audio Sampling |
Television standard sample rate of 48kHz and 24-bit. |
| SDI Color Precision |
10-bit 4:2:2 and 4:4:4. |
| SDI Color Space |
YUV or RGB for inputs, YUV for outputs. |
| SDI Auto Switching |
Automatically selects between SD-SDI and HD-SDI on each input so that each input can be running a different television standard. |
| SDI Metadata Support |
Video payload identification ancillary data as per SMPTE 352M. |
| Control |
| Built in Control Panel |
None |
| External Control Panel |
None |
| Display |
|
None |
| Software |
| Software Control |
MultiView software included free for Windows™
and Mac™. |
| Internal Software Upgrade |
Via included updater application. |
| Operating Systems |
|
Mac 10.15 Catalina,
Mac 11.1 Big Sur or later. |
|
Windows 10,
64-bit. |
| Power Requirements |
| Power Supply |
+12V universal power supply included with international socket adapters for all countries.
Cable tie point. |
| Power Fail Protection |
MultiView 4 HD settings preserved and restored instantly at power on. |
| Power Consumption |
5.5 Watts |
| Operational Voltage Range |
6 to 36V DC |
| Environmental Specifications |
| Operating temperature |
0° to 40° C (32° to 104° F) |
| Storage temperature |
-20° to 45° C (-4° to 113° F) |
| Relative Humidity |
0% to 90% non-condensing |
