| Inputs |
2 x XLR-1/4" TRS Combo Balanced/Unbalanced Mic/Line/Hi-Z Inputs
4 x XLR-1/4" TRS Combo Balanced Mic/Line Inputs
2 x 1/4" TS Unbalanced Line Inputs
1 x 1/8" / 3.5 mm TRRS Unbalanced Smartphone I/O |
| Outputs |
2 x 3-Pin XLR Male Balanced Line Outputs
4 x 1/4" TRS Female Unbalanced Headphone Outputs |
| Input Gain |
Mic/Line Inputs with Hi-Z Off: +10 to +54 dB
Mic/Line Inputs with Hi-Z On: -3 to +41 dB |
| Input Impedance |
XLR: 3 Kilohms
1/4" TRS Line: 3 Kilohms
1/4" TS Line: 10 Kilohms
1/4" Hi-Z: 1 Megohm
3.5 mm TRRS: 10 Kilohms |
| Maximum Input Level |
Mic/Line Inputs (-26 dB Pad Off): -2 dBu at 0 dBFS
Mic/Line Inputs (-26 dB Pad On): +24 dBu at 0 dBFS
1/4" TS Line Inputs: +3 dBu
3.5 mm TRRS: +3 dBu |
| Phantom Power |
+48 VDC |
| Output Impedance |
XLR: 100 Ohms
1/4" TRS: 10 Ohms |
| Maximum Output Level |
XLR: +14.5 dBu
1/4" TRS: 10 mW per Channel (60-Ohm Load) |
| Buses |
Master: 1
Monitor: 3
Send EFX: 1 |
| Channel Control |
Low-Cut Filter: 75 Hz at 12 dB/Octave
High EQ (Shelving): ±15 dB at 10 kHz
Mid EQ (Peaking): ±15 dB at 2.5 kHz
Low EQ (Shelving): ±15 dB at 100 Hz |
| Level Meters |
12 x 9-Segment LEDs |
| Effects |
8 Types |
| Recorder |
Maximum Simultaneous Recording Tracks: 12
Maximum Simultaneous Playback Tracks: 10
Format: WAV
Bit Depth: 16-Bit or 24-Bit
Sample Rate: 44.1, 48, or 96 kHz |
| Supported Media Card Types |
SDHC: 4 to 32 GB (Class 10 or Higher)
SDXC: 64 to 512 GB (Class 10 or Higher) |
| Audio Interface |
Recording: 12 Channels
Playback: 4 Channels
Bit Depth: 24-Bit
Sample Rate: 44.1 or 48 kHz
Interface: USB 2.0 |
| System Requirements |
macOS 10.12 or Later
Intel Core i3 or Faster CPU
USB 3.0 / 2.0 (Operation Is Not Guaranteed When Used with USB Hubs or Expansion Cards)Windows 7 SP1 or Later (32-/64-Bit)
Intel Core i3 or Faster CPU (Operation Is Not Guaranteed with CPUs from Atom, Celeron, or Pentium Series or CPUs Made by AMD)
USB 3.0 / 2.0 (Only USB Host Controllers with Intel Chipsets are Supported; Operation Is Not Guaranteed When Used with USB Hubs or Expansion Cards)iOS 10 or Later
Apple Lightning-to-USB Camera Adapter Required |
| Card Reader |
Class: Mass Storage USB 2.0 High Speed |
| Frequency Response |
20 Hz to 20 kHz -1 dB at 44.1 kHz
20 Hz to 40 kHz -3 dB at 96 kHz (Gain at 3 O'Clock) |
| Equivalent Input Noise |
≤121 dBu EIN (IHF-A) at +54 dB, 150-Ohm Input |
| Display |
96 x 64 Backlit LCD |
| Power Requirements |
Battery: 4 x AA Batteries (Alkaline, NiMH, or Lithium)
AC: Zoom AD-17 AC Adapter
DC: 5 V, 1 A
USB Bus Power |
| Battery Life |
Alkaline: Up to 2 Hours
NiMH (1900 mAh): Up to 3.5 Hours
Lithium: Up to 6.5 HoursTesting Conditions: 4-Channel Recording at 16-Bit / 44.1 kHz to SD Card with Phantom Power Off, LCD Backlight at 15 Seconds, Battery Save On, and 62-Ohm Headphone Impedance |
| Power Consumption |
5 W |
| Dimensions (W x D x H) |
26.8 x 28.2 x 7.4 cm (10.6 x 11.1 x 2.9") |
| Weight |
1.6 kg (3.4 lb) |
